Ultrasonic bin fill-level sensor
Get control of waste fill levels in your bins, dumpsters, and containers
Versatility
Monitoring any type of waste in any type of bins
Build quality and durability
Robust, water- and shock-resistant, fully functional within a wide temperature range
Network connectivity
Sensors can be connected to a variety of IoT networks and GPRS
11,100
sensors
Largest global smart waste installation in Madrid
Problems we solve
- Inefficient collection of empty or half-empty bins
- Delayed collection and overflowing bins
- Absence of real-time data, making waste collection scheduling a challenge
- Poor service quality and no opportunity for verification or supervision
- Rising operating costs
- Outdated route planning
- Difficulty compiling accurate reports and meeting sustainability goals
- Critical situations involving bin infrastructure, such as fire, vandalism, theft, and break-ins
Available ultrasonic sensor types
Single Sensor 5.0
The latest generation of Sensoneo smart waste ultrasonic sensors offers advanced features such as FOTA and GPS.
- Robustness and resistance
- Data transmission via a variety of networks
- Easy to use and deploy
- Large-scale deployment capability
- Versatility of use
- Sophisticated quality assurance
- Designed and developed in-house
- Manufactured in EU
- Citizen engagement
| Measurement | Single ultrasonic beam |
| Measuring range standard (cm) | 3 – 255 |
| Measuring range long-range (cm) | 3 – 1200 |
| Connectivity | LoRaWAN / Sigfox / NB-IoT / CAT-M1 |
| Measurement frequency | From once a day to every 2 minutes |
| Configuration | Mobile app via BLE or downlink |
| FOTA (Firmware Over-the-Air) | Yes |
| Emptying recognition | Accelerometer. Advanced tilt recognition algorithm. |
| GPS functionality | Yes, powered by GNSS |
| Support for connection to external GPS | Yes |
| Support for connection to an external antenna for NB-IoT and Cat-M1 networks | Yes |
| RORO (roll-on/roll-off) | Yes |
| Replaceable batteries | Yes |
| Temperature measurement | Microcontroller thermostat |
| Dimensions in mm (H/W/D) | 50 / 120 / 54 |
| Weight (incl. batteries) | 215 g |
| Casing | IP69 |
| Protection against external mechanical impacts | IK10 rating |
| Material | Recyclable glass fiber-reinforced polyamide |
| Mounting options | Screws / clamp / rails |
We do not limit customers to a specific network. Our customers have sensors connected to several networks — it all depends on the connectivity available at a given location. Single Sensor 5.0 from Sensoneo can be connected to either NB-IoT or the Cat-M1 network. Data is sent in real time to our Smart Waste Management System, one of the best waste management software solutions on the market.
Payload and network communication are encrypted on two levels, preventing misuse of Sensoneo Sensors for DDoS attacks.
Sensoneo Smart Sensors can provide service verification for your pickup. The sensor has a built-in accelerometer that recognizes both horizontal and vertical movement. With careful configuration for your bin design, vehicle pickup system, and emptying movement, the Smart Sensor can detect a pickup and send a notification to the dashboard.
Installing Sensoneo Smart Sensors is quick and straightforward, with no technical expertise required. Many customers choose to handle the configuration themselves, thanks to the solution’s intuitive and user-friendly design. To guide you through setup and installation, we provide clear instructions, detailed user guides, and step-by-step video manuals. Be sure to review all materials carefully to ensure a smooth and successful deployment.
FOTA
Firmware over the Air
GPS Functionality
Powered by GNSS
IP69 and IK10
Casing and protection against external mechanical impacts
Single Sensor 3.0
The reliable and affordable version of our ultrasonic sensor, proving its competitive advantage in large-scale projects around the world.
- Robustness and resistance
- Data transmission via a variety of networks
- Easy to use and deploy
- Large-scale deployment capability
- Versatility of use
- Sophisticated quality assurance
- Designed and developed in-house
- Manufactured in EU
- Citizen engagement
| Measurement | Single ultrasonic beam |
| Measuring range (cm) | 3 – 255 |
| Connectivity | LoRaWAN / Sigfox / NB-IoT |
| Measurement frequency | Up to 24 measurements per day, once per hour |
| Configuration | Mobile app via BLE or downlink |
| Emptying recognition | Accelerometer. Advanced tilt recognition algorithm. |
| Replaceable batteries | Yes |
| Temperature measurement | Microcontroller thermostat |
| Dimensions in mm (H/W/D) | 50 / 120 / 54 |
| Weight (incl. batteries) | 215 g |
| Casing | IP69 |
| Protection against external mechanical impacts | IK10 rating |
| Material | Recyclable glass fiber-reinforced polyamide |
| Mounting options | Screws / clamp / rails |
We do not limit customers to a specific network. Our customers have sensors connected to several networks – it all depends on the connectivity available at a given location. Single Sensor 3.0 from Sensoneo can be connected to a variety of IoT networks – Sigfox, LoRaWAN, and NB-IoT. Data is sent in real time to our Smart Waste Management System, one of the best waste management software solutions on the market.
Payload and network communication are encrypted on two levels, preventing misuse of Sensoneo Sensors for DDoS attacks.
Sensoneo Smart Sensors can provide service verification for your pickup. The sensor has a built-in accelerometer that recognizes both horizontal and vertical movement. With careful configuration for your bin design, vehicle pickup system, and emptying movement, the Smart Sensor can detect a pickup and send a notification to the dashboard.
Installing Sensoneo Smart Sensors is quick and straightforward, with no technical expertise required. Many customers choose to handle the configuration themselves, thanks to the solution’s intuitive and user-friendly design. To guide you through setup and installation, we provide clear instructions, detailed user guides, and step-by-step video manuals. Be sure to review all materials carefully to ensure a smooth and successful deployment.
Accelerometer
Advanced tilt recognition algorithm
Recyclable
Made from glass fiber reinforced polyamide
IP69 and IK10
Casing and protection against external mechanical impacts
Quatro Sensor
Our longest-lasting sensor is the safest option in areas without IoT network coverage. Thanks to its robust casing, it can hold two batteries, ensuring longer operating life.
- Robustness and resistance
- Data transmission via a variety of networks
- Easy to use and deploy
- Large-scale deployment capability
- Versatility of use
- Sophisticated quality assurance
- Designed and developed in-house
- Manufactured in EU
- Citizen engagement
| Measurement | Four ultrasonic beams |
| Measuring range (cm) | 15 – 400 |
| Connectivity | GPRS / NB-IoT / LoRaWAN / Sigfox |
| Measurement frequency | Up to 24 measurements per day, once per hour |
| Configuration | Mobile app via BLE or downlink |
| Overturn notification | Accelerometer |
| GPS functionality | Yes, powered by GNSS |
| Replaceable batteries | Yes |
| Temperature measurement | Microcontroller thermostat |
| Dimensions in mm (H/W/D) | 63 / 200 / 87 |
| Weight (incl. batteries) | 760 g |
| Casing | IP67 |
| Material | Recyclable glass fiber-reinforced polyamide |
| Mounting options | Screws / clamp / rails |
We do not limit customers to a specific network. Our customers have sensors connected to several networks – it all depends on the connectivity available at a given location. Quatro Sensor from Sensoneo can be connected to a variety of IoT networks – Sigfox, LoRaWAN, and NB-IoT. If an IoT network is not available, GPRS is an option. Data is sent in real time to our Smart Waste Management System, one of the best waste management software solutions on the market.
Payload and network communication are encrypted on two levels, preventing misuse of Sensoneo Sensors for DDoS attacks.
Sensoneo Smart Sensors can provide service verification for your pickup. The sensor has a built-in accelerometer that recognizes both horizontal and vertical movement. With careful configuration for your bin design, vehicle pickup system, and emptying movement, the Smart Sensor can detect a pickup and send a notification to the dashboard.
Installing Sensoneo Smart Sensors is quick and straightforward, with no technical expertise required. Many customers choose to handle the configuration themselves, thanks to the solution’s intuitive and user-friendly design. To guide you through setup and installation, we provide clear instructions, detailed user guides, and step-by-step video manuals. Be sure to review all materials carefully to ensure a smooth and successful deployment.
GPRS connectivity
When IoT network is not available
Microcontroller termostate
Temperature measurement
Measuring range
Up to 400cm
Competitive advantage
- Dynamic waste collection with no unnecessary routing
- Collection of only full bins and containers, saving resources for bins in remote locations
- Clean streets, with no overflowing bins or mess
- Best possible service for the money invested in waste collection
- A real overview of waste generation thanks to comprehensive data
- Rightsizing of collection frequencies, capacities, or locations
- Supervision of collection efficiency
- Reducing CO2 emissions, easing traffic congestion, and engaging residents
